Display Interface Module Card Parameters; Ifc: Interface Cards (1) Gif: Get Interface Card Info - 3Com CoreBuilder 9000 User Manual

Display Interface
Module Card
Parameters
Port Interface Media type
id type
------ ---------- --------------------- ------------
5.1.1 OC3-SC
. 5.1.2 OC3-SC
5.1.3 OC3-SC
5.1.4 OC3-SC
5.2.1 OC12-SC
5.2.2 155-RJ45
5.2.3 155-RJ45
5.2.4
Display parameters of an installed interface module. You are prompted to
specify an interface module for display.
Command Actions
Enter the menu sequence: (1) SYS: Platform configuration
Enter a parameter at the prompt
Parameter
Slot ID
Direct access sequence:
Co
mmand Result
System action taken:
System message display:
Example
Enter:
1 5 1 5
Parameters of the ports of the selected ATM Interface Module in slot 5
are displayed in the example. The ATM Interface Module contains an
OC-12c/STM-4 card, an OC-3c/STM-1 card, and a 155 Mbps-over-UTP5
card.
MM fiber
MM fiber
MM fiber
MM fiber
MM fiber
UTP_5 Copper(User)
UTP_5 Copper(User)
Configuring Interface Modules
(5) IFC: Interface cards
(1) GIF: Get interface card info
Format or Range
1 through 7 for the 7-slot chassis, and 1through 7, 10,
12, 14, and 16 for the 16-slot chassis for interface
module information or 0 for general slot information
1 5 1 [parameters]
Interface Card parameters for the ATM Interface
Module in slot "slot ID" or slot parameters (for slot ID
= 0) are displayed.
Information is displayed as shown in the examples.
Operational Port
status status mode
-------- ----- --- ------
Up & Connect Disabled SONET Int None
Up & Connect Enabled
Up Enabled
Up Enabled
Up Enabled
Up Enabled
Up Enabled
Not exist Enabled
103
Frame Clk Loop
src mode
SONET Int None
SONET Int None
SONET Int None
SONET Int None
SONET Int None
SONET Int None
SONET Int None
