Standards and

Protocols

Supported

ATM

Protocols


MIBs Supported — MIB II, AToM MIB, RMON MIB, Interface Evolution
MIB, NCDCHASS MIB (private)


ATM Forum Standards Compliance


Electromagnetic Compatibility — FCC Part 15, EN50081-1 (EN55022
Class B); EN50082-1 (IEC 801-2, IEC 801-3, IEC 801-4)


Safety — EN60950, UL1950, CSA22.2, TUV, IEEE 825-1, 852-2; PCB
UL94V-O; PCB; ANSI/IEEE; RB-276 Class 2
This section describes the major standards and protocols used within the
CoreBuilder 9000 ATM Enterprise Switch and the network applications
and topologies that you can use.
The CoreBuilder 9000 ATM Enterprise Switch uses ATM technology,
including connection protocols, user-to-network and network-to-network
interfaces. You can directly control all features via device management.
For more information about ATM, see Chapter 10.
The CoreBuilder 9000 ATM Enterprise Switch uses numerous protocols to
connect to and communicate with other devices in the network. Among
the protocols used is the Integrated Local Management Interface (ILMI),
which is used to connect over the user-to-network interface (UNI) and
network-to-network interface (NNI), as well as for address registration.
Signalling (Q2931) for Switched Virtual Connection (SVC) is used for
dynamically managing calls. IISP, E-IISP are implemented for multiple
switch networks.


Communications Protocols — RFC 826 ARP, RFC 791 IP, RFC 792
ICMP, RDC 768 UDP, RFC 793 TCP


Ethernet Protocols — IEEE 802.1d, IEEE 802.3


Management Protocols — RFC 1157 SNMP, RFC 1212 Concise, RFC
1213 MIB II, RFC 1212 Traps.
