264 C 9: M
HAPTER ANAGING
Assign Redundant
LES to ELAN
LAN E
MULATION
Assign a LES to be the redundant (secondary) LES of a specified ELAN in
the LECS database. Specify the ELAN name and the ATM address of the
LES. The secondary LES should reside on a different switch than the
primary LES. For more information, see "LES Redundancy Facility —
Configuring the ELAN Topology Database" on page 394.
Command Actions
Enter menu sequence:
Enter a parameter at the prompt
Parameter
ELAN name
LES ATM address
Direct access sequence:
Command Result
System action taken:
System message display:
Example
Enter:
2 1 5 9 1 elan73_9
47.0.0.0.0.0.3c.0.0.d0.0.0.0.0.1.2.3.4.5.6
The following message is displayed:
Redundant LES successfully added.
The specified LES is assigned to be the secondary LES for the specified
ELAN in the LECS database.
(2) LEM: LAN Emulation
(1) LCS: LE Configuration Services
(5) LNT: LECS Network topology
(9) RDN: LE Service redundancy
(1) ALS: Add redun. LES to elan
Format or Range
Up to 32 characters. (For more information, see
"Display ELANs" on page 245.)
20 Hex bytes separated by periods
2 1 5 9 1 [parameters]
The specified LES is assigned to be the secondary LES
for the specified ELAN in the LECS database.
Redundant LES successfully added.
