19
Viewing Network
Statistics
V
IEWING
This chapter explains how to view network statistics to help you perform
some related diagnostic tasks.
If you have problems that are not addressed in this chapter, see
Appendix D.
At any time after you configure the CoreBuilder
Swtich, you may want to view the available statistics to see how well the
network is functioning. For example, you may want to display the general
statistics for an overview of the network, or the signalling statistics for
protocol information on specific ports.
To view statistics:
1 From the CoreBuilder 9000 LMA Main Menu, enter 4 to access the
Statistics menu (STS).
2 Type the number indicated in Table 62 to view the desired statistic type.
Table 62 The Statistics Menu
Menu Option
1 PHY:
Physical Layer
(continued)
N
ETWORK
Description
Displays the physical layer statistics for a specified port.
The data displayed in the physical layer statistics can be
referenced in the event that the link status LED does not light
up. If the values of the data are not all "0", the connection
has not been successful.
S
TATISTICS
® 9000 ATM Enterprise
