424 C 19: V
HAPTER IEWING
N S
ETWORK TATISTICS
Table 62 The Statistics Menu (continued)
Menu Option
2 ATM:
ATM Layer
3 AAL:
AAL5 layer
4 CTL:
Control Frames
5 SIG: Signaling
Description
The ATM layer statistics can be consulted if, for example, a
VPI/VCI is not recognized when setting up a call. These
statistics also provide information on the capacity of traffic
within ports. .
Use the PRT option to display the ATM layer statistics for a
specified port. Use the VPC option to display the ATM layer
statistics for a VPI/VCI of a specified port. If the VPI/VCI is in a
Point-to-Multipoint, call the transmit or receive information is
not always applicable, because it is a call in one direction
only.
Displays counters of AAL5 frames of LAN Emulation such as
LESs or BUSs traffic.
Displays the control frames (AAL5 layer) statistics, including
protocol information, for a specified port.
Displays the signaling protocol statistics for a specified port.
