CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.16.7

(INFO) REMCONT (Remote Control information)

This screen shows if the unit is in Local or Remote mode, and gives details of the
electrical interface type selected, the unit's address, and the baud rate selected, etc.
Pressing ENTER or CLEAR takes the user back to the previous menu. Example:
Remote M&C: Monitor Only
(Local Control only)
Further examples:
Remote M&C: RS485-4Wire
Address: 0001 19200 Baud
Remote M&C: 100BaseTx
IP Addr: 255.255.255.255
6.16.8

(INFO) MASK (Alarm mask information)

This shows, in the same format as the CONFIG, Mask sub menu, which alarms are
currently masked. If an alarm is not masked, a blank is displayed in the relevant screen
position.
Mask: FIFO BPV TAIS RAIS
AGC EbNo BUF Ref BUC LNB
6.16.9

(INFO) REF (Frequency Reference)

This shows the source of the frequency reference for the CDM-570/570L.
Frequency Reference:
Internal 10 MHz (ENTER)
6–53
Revision 3
MN/CDM570L.IOM
