xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
PDU Priority
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.

CFM Packet Counter

This window is used to display the CFM packet counter information. This window does not count CCM packet
statistics of the MEPs in CFM hardware mode.
To view this window, click OAM > CFM > CFM Packet Counter, as shown below:
The fields that can be configured are described below:
Parameter
Port List
Type
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information entered in the fields.
The 802.1p priority to be set in the transmitted LTM. If not specified, it uses the same
priority as CCMs sent by the MA.
Figure 11-16 CFM Packet Counter window
Description
Enter a port or range of ports to display. Tick the All Ports check box to display all
ports.
Transmit – Selecting this option will display all the CFM packets transmitted.
Receive – Selecting this option will display all the CFM packets received.
CCM – Selecting this option will display all the CFM packets transmitted and received.
512
