xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
RIP State
Update Time (1-65535)
Timeout Time (1-65535)
Garbage Collection
Time (1-65535)
Interface Name
Click the Apply button to accept the changes made for each individual section.
Click the Find button to find the specified entry.
Click the View All button to view all the entries.
Click the Edit button to re-configure the selected entry.
After clicking the Edit button, the following window will appear.
The fields that can be configured are described below:
Figure 6-82 RIP Settings window
Description
Click the radio buttons to enable or disable RIP globally. The default setting is
Disabled.
Enter the value of the rate at which RIP updates are sent.
Enter the value of the time after which a RIP route is declared to be invalid.
Enter the value of the time for which a RIP route will be kept before it is removed
from routing table.
Specifies the IP interface name to display.
Figure 6-83 RIP Settings – Edit window
