xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
VLAN Name
VID List
Max Learning
Address (0-3328)
Click the Apply button to accept the changes made.

Port Security Entries

This window is used to remove an entry from the port security entries learned by the Switch and entered into the
forwarding database.
To view this window, click Security > Port Security > Port Security Entries as shown below:
The fields that can be configured or displayed are described below:
Parameter
VLAN Name
VID List
Port List
MAC Address
Lock Mode
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the entries based on the information entered.
Click the Show All button to display all the existing entries.
Click the Clear All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
Description
Click the radio button and enter the VLAN Name.
Click the radio button and enter a list of the VLAN ID.
Enter the maximum number of port-security entries that can be learned by this VLAN.
Tick the No Limit check box to have unlimited number of port-security entries that
can be learned by this VLAN.
Figure 9-55 Port Security Entries window
Description
The VLAN Name of the entry in the forwarding database table that has been
permanently learned by the Switch.
The VLAN ID of the entry in the forwarding database table that has been permanently
learned by the Switch.
Enter the port number or list here to be used for the port security entry search. When
All is selected, all the ports configured will be displayed.
The MAC address of the entry in the forwarding database table that has been
permanently learned by the Switch.
The type of MAC address in the forwarding database table.
432
