DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
intf-name: Interface name on which virtual router is based.
Event description: One virtual router state becomes Init.
Log Message: VR <vr-id> at interface <intf-name> switch to Init
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Event description: Authentication type mismatch of one received VRRP
advertisement message.
Log Message: Authentication type mismatch on VR <vr-id> at interface <intf-
name>
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Event description: Authentication checking fail of one received VRRP
advertisement message.
Log Message: Authentication fail on VR <vr-id> at interface <intf-name>.
Auth type <auth-type>
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Auth-type: VRRP interface authentication type.
Event description: Checksum error of one received VRRP advertisement
message.
Log Message: Received an ADV msg with incorrect checksum on VR <vr-id>
at interface <intf-name>
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Event description: Virtual router ID mismatch of one received VRRP
advertisement message.
Log Message: Received ADV msg virtual router ID mismatch. VR <vr-id> at
interface <intf-name>
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Event description: Advertisement interval mismatch of one received VRRP
advertisement message.
Log Message: Received ADV msg adv interval mismatch. VR <vr-id> at
interface <intf-name>
Parameters description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Event description: A virtual MAC address is added into switch L2 table
Log Message: Added a virtual MAC <vrrp-mac-addr> into L2 table
Parameters description:
vrrp-mac-addr: VRRP virtual MAC address
Event description: A virtual MAC address is deleted from switch L2 table.
Log Message: Deleted a virtual MAC <vrrp-mac-addr> from L2 table
Parameters description:
vrrp-mac-addr: VRRP virtual MAC address
Event description: A virtual MAC address is adding into switch L3 table.
Log Message: Added a virtual IP <vrrp-ip-addr> MAC <vrrp-mac-addr> into
L3 table
Parameters description:
vrrp-ip-addr: VRRP virtual IP address
vrrp-mac-addr: VRRP virtual MAC address
Event description: A virtual MAC address is deleting from switch L3 table.
Log Message: Deleted a virtual IP <vrrp-ip-addr> MAC <vrrp-mac-addr>
from L3 table
Parameters description:
vrrp-ip-addr: VRRP virtual IP address
Informational
Warning
Warning
Warning
Warning
Warning
Notice
Notice
Notice
Notice
577
