xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Chapter 2

Introduction

Login to the Web Manager

Web-based User Interface

Web Pages
Introduction
Most software functions of the DGS-3620 Series switches can be managed, configured and monitored via the
embedded web-based (HTML) interface. Manage the Switch from remote stations anywhere on the network
through a standard browser. The browser acts as a universal access tool and can communicate directly with the
Switch using the HTTP protocol.
Login to the Web Manager
To begin managing the Switch, simply run the browser installed on your computer and point it to the IP address you
have defined for the device. The URL in the address bar should read something like: http://123.123.123.123, where
the numbers 123 represent the IP address of the Switch.
NOTE: The factory default IP address is 10.90.90.90 for normal ports. The factory default IP address
is 192.168.0.1 is for the management port.
This opens the management module's user authentication window, as seen below. The following example is from
10.90.90.90.
Leave both the User Name field and the Password field blank and click OK. This will open the Web-based user
interface. The Switch management features available in the web-based manager are explained below.
Web-based User Interface
The user interface provides access to various Switch configuration and management windows, allows you to view
Web-based Switch Configuration
Figure 2-1 Enter Network Password window
15
