xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Maximum Frame Size
Power Via MDI
Click the Apply button to accept the changes made.

LLDP Statistic System

The LLDP Statistics System page allows you an overview of the neighbor detection activity, LLDP Statistics and
the settings for individual ports on the Switch. To view the following window, click L2 Features > LLDP > LLDP>
LLDP Statistic System, as shown below:
Select a Unit and Port number from the drop-down menu and click the Find button to view statistics for a certain
unit and port.

LLDP Local Port Information

The LLDP Local Port Information page displays the information on a per port basis currently available for
populating outbound LLDP advertisements in the local port brief table shown below.
To view the following window, click L2 Features > LLDP > LLDP> LLDP Local Port Information, as shown below:
what is the aggregated port ID. The default state is Disabled.
The Maximum Frame Size indicates that LLDP agent should transmit 'Maximum-
frame-size TLV. The default state is Disabled.
Use the drop down menu to specify whether LLDP agent should transmit Power via
MDI TLV. Three IEEE 802.3 PMD implementations (10BASE-T, 100BASE-TX, and
1000BASE-T) allow power to be supplied over the link for connected non-powered
systems. The Power Via MDI TLV allows network management to advertise and
discover the MDI power support capabilities of the sending IEEE 802.3 LAN station.
The default state is Disabled.
Figure 5-113 LLDP Statistics System window
