xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
Pdelay Request
Interval (1-32)
Click the Apply button to accept the changes made.

PTP Clock Information

This window is used to display the active attributes of the PTP clock. When PTP State is disabled in PTP Global
Settings window, PTP Clock Identity displays 0000000000000000.
To view this window, click L2 Features > PTP > PTP Clock Information, as shown below:
Figure 5-129 PTP Peer to Peer Transparent Port Settings window
Description
Select the switch unit to configure.
Select the port range to use for this configuration.
Enter the permitted mean time interval between successive pdelay_request
messages.
187
