xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Parameter
Profile ID
Profile Name
Access ID (1-128)
Click the Find button to locate a specific entry based on the information entered.
Click the Add button to add a new entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Modify button to re-configure the specific entry.
Click the View button to display the information of the specific entry.
Click the Delete button to remove the specific entry.
After clicking the Add or Modify button, the following page will appear:
The fields that can be configured are described below:
Parameter Description
Profile ID Enter the Profile ID for the flow meter.
Profile Name Enter the Profile Name for the flow meter.
Access ID Enter the Access ID for the flow meter.
Mode Rate – Specify the rate for single rate two color mode.
Rate – Specify the committed bandwidth in Kbps for the flow.
Description
Here the user can enter the Profile ID for the flow meter.
Here the user can enter the Profile Name for the flow meter.
Here the user can enter the Access ID for the flow meter.
Figure 8-65 Egress ACL Flow Meter Configuration window
