xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Ports/VID List
Access
Profile ID/Profile
Name
Click the Apply button to accept the changes made.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specific entry.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

IPv6 Max Multicast Group Settings

Users can configure the ports and VLANs on the switch that will be a part of the maximum filter group, up to a
maximum of 1024.
The fields that can be configured are described below:
Parameter
Ports/VID List
Max Group
Infinite
Figure 5-100 IPv6 Limited Multicast Range Settings window
Description
Select the appropriate port(s) or VLAN IDs used for the configuration here.
Assign access permissions to the ports selected. Options listed are Permit and Deny.
Use the drop-down menu to select the profile ID or profile name used and then assign
Permit or Deny access to them.
Figure 5-101 IPv6 Max Multicast Group Settings window
Description
Select the appropriate port(s) or VLAN IDs used for the configuration here.
If the checkbox Infinite is not selected, the user can enter a Max Group value.
Tick the check box to enable or disable the use of the Infinite value.
165
