xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Interface Name
Click the Find button to find the interface entered.
Click the View All button to view all PIM for IPv6 neighbors on this switch.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
PIM for IPv6 Multicast Route Table
This window is used to display the current PIM for IPv6 multicast route table.
To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv6 > PIM for
IPv6 Multicast Route Table, as shown below:
The fields that can be configured are described below:
Parameter
Group Address
Click the Find button to find the group address entered.
Click the View All button to view all PIM for IPv6 multicast routes on this switch.
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link to see the following window.
Figure 6-121 PIM for IPv6 Neighbor Table window
Description
Enter the name of the IP interface for which you want to display the current PIM for
IPv6 neighbor routing table.
Figure 6-122 PIM for IPv6 Multicast Route Table window
Description
Enter the IPv6 multicast group address.
271
