D-Link xStack Reference Manual page 484

®
xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Pool Name
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the Edit button under various columns to re-configure the specific entry.
Click the Delete button to remove the specific entry.
Click the Edit button under Excluded Address to see the following window.
The fields that can be configured are described below:
Parameter
Begin Address
End Address
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to return to the previous window.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the specific entry.
Click the Edit button under Manual Binding to see the following window.
The fields that can be configured are described below:
Parameter
IPv6 Address
Network Address
Enter the DHCPv6 Server Pool name.
Figure 10-20 DHCPv6 Server Excluded Address Settings window
Description
Enter the beginning IPv6 address of the range of IPv6 addresses to be excluded from
the DHCPv6 pool.
Enter the ending IPv6 address of the range of IPv6 addresses to be excluded from the
DHCPv6 pool.
Figure 10-21 DHCPv6 Server Manual Binding Settings window
Description
Enter the IPv6 address to be statically bound to a device.
Enter the IPv6 networks address that will be statically bound to a device here.
483
