To view the following window, click QoS > DSCP > DSCP Map Settings and select DSCP DSCP from the DSCP
Map drop-down menu, as show below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
DSCP Map
Figure 7-8 DSCP Map Settings - DSCP Priority window
Figure 7-9 DSCP Map Settings - DSCP DSCP window
Description
Select the unit you want to configure.
Use the drop-down menu to select a range of port to configure.
Use the drop-down menu to select one of two options:
