D-Link xStack Reference Manual page 56

®
xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Click the Find button to locate a specific entry based on the information entered.
Click the Add button to add a new entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the IPv4 Edit button to edit the IPv4 settings for the specific entry.
Click the IPv6 Edit button to edit the IPv6 settings for the specific entry.
Click the Delete button to remove the specific entry.
NOTE: To create IPv6 interfaces, the user has to create an IPv4 interface then edit it to IPv6.
Click the Add button to see the following window.
The fields that can be configured are described below:
Parameter
Interface Name
IPv4 Address
Subnet Mask
VLAN Name
Interface Admin State
Secondary Interface
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
Click the IPv4 Edit button to see the following window.
Figure 4-9 IPv4 Interface Settings window
Description
Enter the name of the IP interface being created.
Enter the IPv4 address used.
Enter the IPv4 subnet mask used.
Enter the VLAN Name used.
Use the drop-down menu to enable or disable the Interface Admin State.
Tick the check box to use this Interface as a Secondary Interface.
Figure 4-10 IPv4 Interface Settings – Edit window
55
