xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
Port
Ports
Click the Find button to locate a specific entry based on the port number selected.
Click the Clear button to clear all the information entered in the fields.
Click the View All button to display all the existing entries.

MAC-based Access Control (MAC)

MAC-based access control is a method to authenticate and authorize access using either a port or host. For port-
based MAC-based access control, the method decides port access rights, while for host-based MAC-based access
control, the method determines the MAC access rights.
A MAC user must be authenticated before being granted access to a network. Both local authentication and remote
RADIUS server authentication methods are supported. In MAC-based access control, MAC user information in a
local database or a RADIUS server database is searched for authentication. Following the authentication result,
users achieve different levels of authorization.
Notes about MAC-based Access Control
There are certain limitations and regulations regarding MAC-based access control:
•
Once this feature is enabled for a port, the Switch will clear the FDB of that port.
•
If a port is granted clearance for a MAC address in a VLAN that is not a Guest VLAN, other MAC
addresses on that port must be authenticated for access and otherwise will be blocked by the
Switch.
•
Ports that have been enabled for Link Aggregation and Port Security cannot be enabled for MAC-
based Authentication.
•
Ports that have been enabled for GVRP cannot be enabled for Guest VLAN.

MAC-based Access Control Settings

This window is used to set the parameters for the MAC-based access control function on the Switch. The user can
set the running state, method of authentication, RADIUS password, view the Guest VLAN configuration to be
associated with the MAC-based access control function of the Switch, and configure ports to be enabled or
disabled for the MAC-based access control feature of the Switch. Please remember, ports enabled for certain other
Figure 9-32 ND Snooping Entry window
Description
Select the switch unit to configure.
Use the drop-down menu to select the desired port.
Specify the ports for ND snooping entries. Tick the All Ports check box to select all
entries for all ports.
408
