DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide

Click the Show All Rules button to navigate back to the CPU Access Rule List.

Adding a CPU IPv6 ACL Profile

The window shown below is the Add CPU ACL Profile window for IPv6. To use specific filtering masks in this ACL

profile, click the packet filtering mask field to highlight it red. This will add more filed to the mask.

After clicking the Add CPU ACL Profile button, the following page will appear:

The fields that can be configured are described below:

Profile ID (1-5)

Select ACL Type

Figure 8-33 CPU Access Rule Detail Information (IPv4 ACL) window

Figure 8-34 Add CPU ACL Profile (IPv6 ACL) window

Enter a unique identifier number for this profile set. This value can be set from 1

Select profile based on Ethernet (MAC Address), IPv4 address, IPv6 address, or

packet content mask. This will change the menu according to the requirements for

the type of profile.
