xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Max Learning Address
(0-3328)
Click the Apply button to accept the changes made for each individual section.
Click the Edit button to re-configure the specific entry.
Click the View Detail button to display the information of the specific entry.
Click the View Detail button to see the following window.
The fields that can be configured are described below:
Parameter
VLAN Name
VID List
Max Learning Address
(0-3328)
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.

Port Security VLAN Settings

This window is used to configure the maximum number of port-security entries that can be learned on a specific
VLAN.
To view this window, click Security > Port Security > Port Security VLAN Settings as shown below:
Specify the maximum value of port security entries that can be learned on this port.
Figure 9-53 Port Security Port-VLAN Settings window
Description
Click the radio button and enter a VLAN name.
Click the radio button and enter a list of VLAN ID.
Enter the maximum number of port security entries that can be learned by this VLAN.
If this parameter is set to 0, it means that no user can be authorized on this VLAN.
If the setting is lower than the number of current learned entries on the VLAN, the
command will be rejected. Tick the No Limit check box to have unlimited number of
port security entries that can be learned by a specific VLAN.
The default value is No Limit.
Figure 9-54 Port Security VLAN Settings window
431
