xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
Click the Delete button to remove the specific entry.
Click the Clear Counter button to see the following window.
The fields that can be configured are described below:
Parameter
Prefix List Name
IP Address
Mask Address
Click the Clear button to remove the information entered.
Click the <<Back button to return to the previous window.
Click the Clear All button to remove all the entries.
Click the View Detail link to see the following window.
The fields that can be configured are described below:
Parameter
Sequence ID (1-
65535)
Direction
Prefix Address
Prefix Mask
GE (1-32)
LE (1-32)
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to return to the previous window.
Figure 6-172 IP Prefix List Settings - Clear Counter window
Description
Enter the name of the prefix list that will be cleared.
Enter the IP address to be cleared.
Enter the mask address to be cleared.
Figure 6-173 IP Prefix List Settings - View Detail window
Description
Enter the sequence number for the rule entry.
Use the drop-down menu to Permit or Deny the specified network.
Enter the network address.
Enter the mask address of the network address.
Enter the minimum prefix length to be matched.
Enter the maximum prefix length to be matched.
303
