Locate the Server

Name
Battery
Cables
DIMMs
Drives
Drive backplanes
NVMe drives
Fan modules
Filter
LED board
Motherboard
Network interfaces
PCIe cards
Internal HBA PCIe card
PDB
Power supplies
USB board
eUSB flash drive
Related Information
"Removing Power From a Server" on page 49
■
"Accessing Internal Components" on page 55
■
Locate the Server
You can use the Locator LEDs to pinpoint the location of a server. This procedure is helpful
when you need to identify one particular server from many others in the same rack.
1. Access Oracle ILOM.
See "Log In to Oracle ILOM (Service)" on page
2. Turn on the Locator LED.
-> set /SYS/LOCATE value=Fast_Blink
The white Locator LEDs (one on the front panel and one on the rear panel) blink.
48 Netra SPARC S7-2 Server Service Manual • February 2017
Oracle ILOM Target
/SYS/MB/CMPw/MCUx/CHy/Dz
/SYS/DBP/HDDx
/SYS/DBP
/SYS/MB/FMx
/SYS/MB
/SYS/MB/NETx
/SYS/MB/PCIEy
/SYS/PDB
/SYS/PSx
Service Link
"Servicing the Battery" on page 189
"Servicing the Cables" on page 193
"Servicing DIMMs" on page 159
"Servicing SAS Drives" on page 85
"Servicing the Drive Backplane" on page 117
"Servicing NVMe Storage Drives" on page 97
"Servicing Fan Modules" on page 151
"Servicing the Air Filter" on page 79
"Servicing the LED Board" on page 217
"Servicing the Motherboard" on page 225
"Servicing the Motherboard" on page 225
"Servicing PCIe Cards" on page 169
"Servicing the Internal HBA PCIe Card" on page 179
"Servicing the PDB" on page 141
"Servicing Power Supplies" on page 131
"Servicing the USB Board" on page 109
"Servicing the eUSB Drive" on page 103
