See "Rotate the Drive Cage to the Service Position" on page
Related Information
"Remove the Top Cover" on page 67
■
"Install the Fan Tray" on page 244
■
"Rotate the Drive Cage to the Service Position" on page 71
■

Rotate the Drive Cage to the Service Position

1. Complete these prerequisites in this order.
a. "Remove the Top Cover" on page 67
"Remove a Fan Module" on page 153
b.
Note - Remove all fan modules.
"Remove the Fan Tray" on page 69
c.
Disconnect the cables attached to the drive backplane, and the cable attached to
2.
the USB board.
See "Cable Configurations" on page 194
For easier removal, first press the cables in, then press the release tab, then pull the cables
Tip -
out,
The cables are shown in the illustration in
3. Fully insert or remove any partially removed drives before continuing.
Rotate the Drive Cage to the Service Position
for location of cables.
"Cable Configurations" on page
71.
194.
Preparing for Service 71
