Remove the SAS Drive Signal Cable
Removing a cable is a cold-service operation. You must power off the server before you remove
the cable.
1. Determine which cable to remove.
See "Cable Configurations" on page
2. Prepare for service.
See "Preparing for Service" on page
3. Remove the fan tray with all fan modules.
See "Remove the Fan Tray" on page
Disconnect the SAS drive signal cable connector from the drive backplane.
4.
See "Cable Configurations" on page
5. Remove the air duct.
See "Remove the Air Duct" on page
6. Disconnect the cable connector from the HBA card in slot 7.
Take a photo or note the cable routing and order for use later when installing the cables.
Tip -
7. Set the cable aside.
8. Consider your next step.
If you are replacing a cable, install the new cable.
■
See
If you removed a cable as part of another component's removal or
■
installation procedure, return to that procedure.
196 Netra SPARC S7-2 Server Service Manual • February 2017
"Install the SAS Drive Signal Cable" on page
194.
43.
69.
194.
75.
197.
