Install the Drive Backplane
"Returning a Server to Operation" on page 235
■
Install the Drive Backplane
Installing the drive backplane is a cold-service operation. You must power off the server before
installing the drive backplane.
1.
Position the drive backplane to where it will install into the server.
The drive backplane aligns with the drive connectors down. The two alignment holes are on the
left, and the single alignment hole is on the right.
122
Netra SPARC S7-2 Server Service Manual • February 2017
