3.
Slide the USB board rearward off of the alignment pin and allow the USB board
to float freely.
Do not disconnect the cable from the USB board.
Note -
Review this information and complete these prerequisites in this order.
4.
See:
"Remove the Filter" on page 79
■
"Rotate the Drive Cage to the Service Position" on page 71
■
Remove the USB Board
Servicing the USB Board
111
