Remove The Fan Tray - Oracle Netra SPARC S7-2 Service Manual

"Servicing the Battery" on page 189
■
"Remove the Fan Tray" on page 69
■
Related Information
"Prevent ESD Damage" on page 55
■
"Removing the Server From the Rack" on page 56
■
"Install the Top Cover" on page 246
■
"Safety Information" on page 44
■

Remove the Fan Tray

1. Complete these prerequisites in this order.
See:
"Remove the Top Cover" on page 67
■
"Remove a Fan Module" on page 153
■
Remove all fan modules.
2. Open the two fan tray locks.
Lift the fan tray straight up and out of the chassis.
3.
The fan tray is inside the latch line of the cable pass through. Take care when lifting
Caution -
out the fan tray so that the cable pass through is not damaged or unseated.
Remove the Fan Tray
Preparing for Service 69
