Remove The Air Duct - Oracle Netra SPARC S7-2 Service Manual

"Servicing the PDB" on page 141
■
"Servicing the Cables" on page 193
■
Related Information
"Remove the Air Duct" on page 75
■
"Install the PSU Duct" on page 240
■

Remove the Air Duct

1. Complete these prerequisites in this order.
a. Remove the top cover.
See "Remove the Top Cover" on page
b. Rotate the drive cage.
See "Rotate the Drive Cage to the Service Position" on page
Remove the PSU duct.
c.
See "Remove the PSU Duct" on page
2. Disconnect the cables, and move them out of the way.
67.
71.
74.
Remove the Air Duct
Preparing for Service 75
