Install the Motherboard

Installing the motherboard is a cold-service operation. You must power off the server before
installing the motherboard.
1. Position the motherboard for installation into the server.
The heatsinks are toward the front of the server, and the ports are at the rear.
Lift the motherboard by the handles, and slowly lower the motherboard into the
2.
chassis.
Take care when using the handles to install the motherboard. These handles are not in
Caution -
weight-balanced locations. Avoid flexing the motherboard.
Take care to clear the four screws at the rear of the chassis. The screws are long and
Caution -
might scratch or damage the motherboard.
Install the Motherboard
Servicing the Motherboard 231
