Remove a PCIe Card

See "Remove a PCIe Card" on page
If you are unable to determine if a PCIe card is faulty, seek further information.
7.
See "Detecting and Managing Faults" on page
Related Information
"PCIe Card Configurations" on page 170
■
"Remove a PCIe Card" on page 174
■
"Verify a PCIe Card" on page 177
■
Remove a PCIe Card
Removing a PCIe card is a cold-service operation. You must power off the server before you
remove the PCIe card.
Note -
Determine which PCIe card to remove.
1.
See "Locate a Faulty PCIe Card" on page
2. Prepare for service.
See "Preparing for Service" on page
3. Remove the server to obtain access to internal components.
See "Accessing Internal Components" on page
174 Netra SPARC S7-2 Server Service Manual • February 2017
This procedure is the same for removing a filler.
174.
25.
172.
43.
55.
