Customer-Replaceable Units

CRUs can be serviced either by the customer or other trained personnel.
Description
Battery
SAS SSD and HDD
NVMe SSD
eUSB flash drive
DIMM
PCIe cards
Internal SAS HBA PCIe card
Air filter
Power cable
Fan module
Power supply
Description
USB port (rear)
Host network 100/1000/10000 ports (NET 0 to 3)
for host
NET MGT RJ-45 network port
SER MGT RJ-45 serial port
Status LEDs:
■ Locator LED and button
■ Service Required LED
■ Power OK LED
Links
"Servicing the Battery" on page 189
"Servicing SAS Drives" on page 85
"Servicing NVMe Storage Drives" on page 97
"Servicing the eUSB Drive" on page 103
"Servicing DIMMs" on page 159
"Servicing PCIe Cards" on page 169
"Servicing the Internal HBA PCIe Card" on page 179
"Servicing the Air Filter" on page 79
"Servicing the Cables" on page 193
"Servicing Fan Modules" on page 151
"Servicing Power Supplies" on page 131
Customer-Replaceable Units
Links
"USB Ports" in Netra SPARC S7-2 Server
Installation Guide
"10 Gigabit Ethernet Ports" in Netra SPARC S7-2
Server Installation Guide
"Log In to Oracle ILOM (Service)" on page 26
"Log In to Oracle ILOM (Service)" on page 26
"Rear Panel LEDs" on page 33
"Rear Panel Components (Service)" on page 18
Identifying Components 19
