4. Remove the air duct.
See "Remove the Air Duct" on page
5. Remove the NVMe cables from the server.
Carefully remove the NVMe cable bundle from the server. Be careful not to snag the cables on
the server components.
Related Information
Oracle 1.6TB NVMe SSD Documentation Library
■
"Component Locations (Storage, Power, NVMe, and Fan Modules)" on page 14
■
"Component Locations (Motherboard, Memory, and PCIe Cards)" on page 16
■
"Preparing for Service" on page 43
■
"Install NVMe Cables" on page 209
■
"Returning a Server to Operation" on page 235
■

Install NVMe Cables

Replacing the cable assembly is a cold-service procedure that must be performed by qualified
service personnel. The server must be completely powered down before performing this
procedure.
1. Install the NVMe cables between the front storage drive backplane and the
motherboard.
Be careful not to break any wires or base connectors when bending and folding a
Caution -
cable.
a. If installing a new cable, bend it near the white tape banding, at the base
connector, to conform with the cable routing.
Tip - Using the handle of a small screwdriver as a form helps bend the cables while protecting
the wires going into the base connectors. If necessary, the white tape banding can be split to
maintain the integrity of the cable.
b. Plug each cable into its port connector until you hear an audible click.
75.
