Remove the PDB Signal Cable

"Component Service Task Reference" on page 47
■
"Preparing for Service" on page 43
■
"Returning a Server to Operation" on page 235
■
Remove the PDB Signal Cable
Removing a cable is a cold-service operation. You must power off the server before you remove
the cable.
1. Determine which cable to remove.
See "Cable Configurations" on page
2. Prepare for service.
See "Preparing for Service" on page
Review this information and complete these prerequisites in this order.
3.
See:
"Remove a Fan Module" on page 153
■
Remove all fan modules.
"Remove the Fan Tray" on page 69
■
"Rotate the Drive Cage to the Service Position" on page
■
"Remove the Air Duct" on page 75
■
"Remove the PSU Duct" on page 74
■
204 Netra SPARC S7-2 Server Service Manual • February 2017
194.
43.
71.
