Oracle Netra SPARC S7-2 Service Manual page 32

Interpreting LEDs
No. LED
5 Service Required LED (amber)
6 Locator LED and button (white)
7 Hard drive status LEDs:
■ Ready to Remove LED (top,
blue)
■ Service Required LED (middle,
amber)
■ OK/Activity LED (bottom,
green)
Related Information
"Rear Panel LEDs" on page 33
■
"Checking for Faults" on page 25
■
"Performing Advanced Troubleshooting" on page 34
■
"Clear a Fault Manually" on page 40
■
32 Netra SPARC S7-2 Server Service Manual • February 2017
Description
Indicates that service is required.
The Oracle ILOM show faulty command provides details about any faults that cause
this indicator to light.
Under some fault conditions, individual component fault LEDs are turned on in
addition to the Service Required LED.
The Locator LED can be turned on to identify a particular system. When on, the LED
blinks rapidly.
Pressing and holding the Locator button for 5 seconds initiates a test of all LEDs in the
LED assembly.
Indicates these conditions:
■ Off – Drive is not ready or is faulty.
■ Steady on –Drive is on and idle.
■ Fast blink – Read or write activity is in progress.
Indicates that the drive can be removed during a hot-plug operation.
Indicates that the drive has experienced a fault condition.
Indicates the drive's availability for use.
■ On – Read or write activity is in progress.
■ Off – Drive is idle and available for use.
