Install The Sas Drive Signal Cable - Oracle Netra SPARC S7-2 Service Manual

See "Component Service Task Reference" on page
Related Information
"Install the SAS Drive Signal Cable" on page 197
■
"Component Locations (Storage, Power, NVMe, and Fan Modules)" on page 14
■
"Component Locations (Motherboard, Memory, and PCIe Cards)" on page 16
■
"Preparing for Service" on page 43
■
"Returning a Server to Operation" on page 235
■

Install the SAS Drive Signal Cable

Installing a cable is a cold-service operation. You must power off the server before installing the
cable.
1. If replacing a faulty cable, fold the new cable with 90-degree bends on each end.
2. Route the cable into the cable pass through:
The cable pass through is fragile. Take care not to torque or stress it, which could
Caution -
cause damage.
Install the SAS Drive Signal Cable
47.
Servicing the Cables 197
