Modem

8.12
Description
The Emerald ICE system has an optionally available internal modem for Remote
RMP Programming support. When equipped, the modem allows dedicated
communications between the system processor and the RMP.
This communication method does not utilize analog port system resources.
One (optional) modem is available via which the system can be programmed and
maintenance performed remotely.
Modem speeds are 1200 bps/ 2400 bps.
Default Settings:
Built‐in Modem – DIR. No. (directory number) is set to 400.
Built‐in Modem – Baud Rate is set to 2400.
Deluxe Telephone Programming
1. Access the Database Item Selection Screen using the procedures in Section
3.2 .
2. Enter 04-13 . Then press the softkey beneath save . This advances to
BUILT_IN MODEM programming.
3. Press the softkey beneath show . This advances to the DIRECTORY
screen
.
4. Press the softkey beneath chg to change the modem directory number.
5. Enter the new directory number that is to be assigned to the modem
resource and press the softkey beneath save . The directory number must
be from those designated for Extension Directory Numbers.
6. Press the softkey beneath next . This advances to the BAUD RATE
programming screen.
7. Press the softkey beneath chg until the appropriate baud rate displays.
