Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 47

2-22
Emerald ICE Installation & Hardware Reference Manual
Disconnect Digit(s): 8 digits max.
Subscriber Calling via Intercom: 4 digits max.
Transfers to VM : 4 digits max.
Busy Forward: 4 digits max.
No Answer Forward: 4 digits max.
Direct Call Forward: 4 digits max.
CO Line Recall: 4 digits max.
CO Line Ringing: 4 digits max.
UCD Overflow: 4 digits max.
Record Digits for Voice Recorder function: 4 max.
Delete Digits: 4 digits max.
Suffix for transferred calls: 2 max.
CO Line Loop Current sensing: Interrupt programmable from 50ms to 2500ms.
Paging: 8 Internal Page Extension Groups; 1 External Page Port; 1 Internal All
Call; 1 System (Internal/External) All Call;
Speed Dialing: 1000 total bins, dynamically allocated.
200 bins at default allocated for system‐wide use.
20 bins at default allocated for extension use (extensions
401‐446 only) (50 possible per extension)
16 digits maximum per bin.
Last Number Redial: 16 digits per station
Save Number Redial: 16 digits per station
User Saved Number (Memo Pad): 16 digits per station
Callback request per station: 1
Camp On by a busy station: 1
Stations Camped on to a station: 1
Stations Camped on to a busy line: 1
Message ‐ Executive Notification: 6 preprogrammed;1 personal per station
Message ‐ Executive Preprogrammed: 6 preprogrammed; 1 personal per station
