Deluxe Model Telephone

The Emerald ICE has one model digital telephone. The Deluxe Telephone is
equipped with a half‐duplex speakerphone for hands‐free conversations and has a
two‐row by sixteen column (32‐character), dot‐matrix, Super Twist, Liquid Crystal
Display (LCD). Directly under the LCD are three Interactive Buttons to enhance
system features operation. During the various features operations these Interactive
Buttons take‐on functions to aid in feature use.
The Super Twist LCD eliminates the need for contrast adjustment and enhances
angled viewing position clarity of displayed data. Since the Emerald ICE includes
Caller ID as a standard feature, the LCD also enables every designated ringing
extension to receive Caller Identification* data for incoming CO line calls.
This feature requires a subscription from the servicing telephone company.
The display provides a visual reference to call progress and call duration, as well
as time and date information. The display also enables the user to send and
receive visual advisory and callback messages. Users may select from six "canned"
messages (i.e., "IN A MEETING," "OUT OF OFFICE"), or they may create a
custom message. Calls from other Emerald ICE telephone users to an extension
with a message active will receive the visual advisory message on their LCD
display.
Each Deluxe Telephone has twenty‐eight (28) Programmable Feature Buttons to
aid the user by providing direct access to system features and resources. There are
also three (3) Interactive Buttons and 8† fixed function buttons.
The Volume Button Bar represents two operations; volume up and volume
down.
Each Deluxe Telephone is equipped with a 2.5 millimeter headset jack. The user
may toggle his speakerphone operation into an out of a special "Headset Mode".
This mode allows the user to easily activate the headset jack via the ON/OFF
button as an alternative to using the speakerphone.
Headset mode is easily enabled or disabled so that the user may quickly select
between use of the headset or speakerphone operations. (Must be idle to change
this setting.)
