Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 273

8-12
Emerald ICE Installation, Programming & Maintenance Manual
6. When finished programming CO Line Name/Labels, press the Volume
v
button ( ) to return to the DB Item Select screen or exit
programming.
RMP Programming
1. Access the RMP using the procedures described in Section 3.3.
2. From the toolbar select RP, Feature Key Programing, DSS to display the
DIR #
following:
Programming Area
3. Click on a Directory Number in the Dir# field. The Dir# will appear in the
Programming Area of the window with the default CO Line name beside
it.
4. Enter a new CO Line name in the CO Line field in the Programming Area.
5. Click on the
Line name will appear in the DIR # area beside the line number.
6. Click on the Close button to close the window without making changes or
click on the Update button and follow the prompts to save the database
changes.
Apply Button to apply the assignment. The new CO
Apply Button
