Emerald ICE Installation, Programming & Maintenance Manual
Flash – PBX Line
Description
Flash – PBX Line is a programmed setting that will determine what flash timing
will be presented to the host telephone system when the Emerald ICE is installed as
a subordinate system. This feature is critical to perform accurate host‐system
functions like PBX call transfer. When used "behind" a PBX, the Emerald ICE
system extensions should have the Flash feature code programmed onto a
Feature/DSS Button for easy access.
The Flash code may be stored in any speed dial location.
The Flash code may be stored in the Last Number Redial buffer. When you
activate redial, a Deluxe Telephone display will show a " / " to indicate the Flash
code.
The Flash time is programmable from 100ms to 1500ms in increments of 100ms
(1/10th of a second).
At a Deluxe Telephone, when the flash code is dialed PBX Flash will be
displayed temporarily.
Single line extensions must generate a hook‐flash on the analog port, then dial
3
! to generate a hookflash on a PBX Line.
Default Settings:
PBX Flash Time is set at 0.6. (Range is: 0.1‐3.0 seconds.)
Deluxe Telephone Programming
1. Access the Deluxe Telephone Programming Features as described in Section
3.2.
2. Enter 03-03 , then press the softkey beneath save . This advances to the
PBX Flash programming screen.
3. Press the softkey beneath chg to select a PBX Flash Time value that
determines what flash timing will be presented to the host telephone
system when the Emerald ICE is installed as a subordinate system.
Available selections are 100-1500 in increments of 100 milliseconds.
3. Press the Volume button (
Screen or exit programming.
v
) to return to the DB Item Selection
