Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 289

8-28
Emerald ICE Installation, Programming & Maintenance Manual
8. Press the Volume button (
Selection Screen or exit programming.
RMP Programming
1. Access the RMP using the procedures described in Section 3.3.
2. From the toolbar select RP, Resource, Modem and Serial Port to display
the following:
3. Select the values for RMTX and SMDR from the drop‐down lists. RS232
Baud Rate and deployed functions of the RS232 ports are configured here.
4. Select the Built‐in Modem ‐ DIR NO from the drop down list. This is the
directory number used to access the modem. E.g. calling into the Emerald
ICE system from a remote local and connecting to the modem is
accomplished by transferring the inbound modem call to this Emerald ICE
modem directory number. (Range: 400‐499; Default: 400)
5. Select the Built‐in Modem ‐ Baud Rate. The data rate at which the built‐in
modem will operate is determined here. Available selections are 1200/2400.
6. Click on the Close button to close the window without making changes or
click on the Update button and follow the prompts to save the database
changes.
v
) to return to the Data Base Item
