Emerald ICE Installation, Programming & Maintenance Manual
66M1-50 Pinouts
Emerald ICE boards equipped with 25 pair AMP‐type cable connectors are:
•
KSU1 610+2 Board
•
12EKT
•
KSU2 Base Board
Refer to the charts on the following pages for pinout designations per cable pair
for each board type and associated connector.
