FAX Tone Detection

11.2
Description
The Emerald ICE system has a standard FAX Tone Detection capability on the sixth
(6th) port of each CO Line board. That is, CO Line ports 6, 12, 18 and 24 have the
circuitry required to detect "CNG" FAX tone. When the system is programmed to
receive a facsimile transmission on one of these CO line circuits, it automatically
answers the ringing line and waits for FAX tone. If the FAX CNG tone is detected
the call is connected to the specified (programmed)facsimile extension.
Default Settings:
CO Line Application – Fax Detection – Fax Destination set to "None" for CO Line
directory numbers 705, 711, 717, and 723. (Range is: any analog extension port
directory number.)
Deluxe Telephone Programming
1. Access the Database Item Selection Screen using the procedures in Section
3.2.
2. Enter 07-02-1 , then press the softkey beneath save . This advances to
the first FAX DETECTION programming screen.
3. Press the softkey beneath chg and enter the CO line number of the analog
port that is connected to the fax machine that will answer fax calls
answered on this line.
4. Press the softkey beneath save .
5. Press the softkey beneath next to program the second fax circuit...
through to the fourth fax circuit, or press the Volume button (
return to the DB Item Selection Screen or exit programming.
Emerald ICE Installation, Programming & Maintenance Manual
v
) to
11-5
