Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 133

5-44
Emerald ICE Installation, Programming & Maintenance Manual
Program the Voice Announcer UCD Group:
7. Select RP, Extension Application, Uniform Call Districution from the
RMP toolbar to display the following window.
8. Select the Hunt Group number from the Hunt Group drop down list to be
used as the VA Group. Click on the Members button. This will display the
UCD: Members window as shown below.
9. Using the drop‐down lists for any of the 24 possible UCD Members , select
the extension directory number of the analog extension to be programmed
as a member of this UCD Group. Click on the Close button on the UCD:
Members window and follow the prompts to return to the UCD:
Parameters window.
10. Click on the Close button on the UCD: Parameters window and on the
Update button and follow the prompts to save the database changes.
