8.3
8-6
Emerald ICE Installation, Programming & Maintenance Manual
Program DSS Console Owner/Port:
3. Click on the DSS Unit that you want to program a Directory Number and
DSS Owner to.
4. Using the drop‐down lists in the DIR NO. and DSS Owner fields, select a
DIR NO. and DSS Owner that you would like to assign to the DSS Unit
being programmed.
5. Click on the
Owner values will appear as shown above.
Program Attendant Extension User Password:
The default password is 9999. Refer to Extension User Password in Section
for programming instructions of this feature.
6. Click on the Close button to close the window without making changes or
click on the Update button and follow the prompts to save the database
changes.

Attendant / Extension DSS Console Button Programming

Description
The Attendant/Extension DSS Console has 60 buttons that may be programmed
for any of the available Emerald ICE system directory numbers. Forty‐eight of the
sixty buttons have dual colored LED's and are user and/or system programmable
for any system directory number; System Speed Dial, CO Lines and DSS/BLF
extensions. The remaining twelve buttons on the Attendant/Extension DSS
Console are not equipped with an LED and are better suited for directory
numbers of features that don't require status indication (like Background Music).
Only directory numbers can be programmed on DSS Console buttons.
The Attendant/Extension DSS Console must be assigned to operate with your
extension in order to program buttons.
Default Settings:
The button map of each DSS Console is defaulted for extensions 401‐448, Auto
Dial (System Speed Dial) 500‐507, All Page, Page Zones 1 and 2, External Page,
Music Channels 1 and 2, and Pick Up Groups 1 and 2.
button to apply the assignment. The DIR NO. and DSS
8.7
