A

Door Phone Installation

General

A.1
Description
The Emerald ICE system permits 2 Door Phone extensions to be connected with the
610+2 Board. The extensions are analog and are used to activate relays which are
connected with the on‐site door opening circuit or ancillary device.
Telephone keys can be programmed using either the Deluxe Telephone or the RMP
to open the door and set the unlocked time.
Up to 6 extensions per door phone can be programmed to ring when the door
phone is activated.
Dimensions
The Door Phone Dimensions are:
W= 3.75 Inches
H= 5 inches
D=1.25 inches
A-1
