6.4
6-10
Emerald ICE Installation, Programming & Maintenance Manual

CO Line Loop Supervision (Talk/Hold Abandon)

Description
CO Line Loop Supervision is a Central Office (Telephone Company) feature. This
feature allows for advanced handling of call connections when the distant end
party disconnects. This function is especially useful when calls that have been
placed on hold go unattended and the distant end party hangs up, or when the
caller is connected to voicemail leaving a message and hangs up. The Emerald ICE
receives the disconnect signal from the telephone company and forces the CO line
on‐hook to release the system resource for other uses.
Default Settings
CO Line – Call Abandon set to Y (yes) for all CO Lines. (Range: Y/N)
Call Handling – Talk Abandon Time set at 600ms. (Range: 50‐1000ms)
Call Handling – Hold Abandon Time set at 600ms. (Range: 50‐1000ms)
Deluxe Telephone Programming
1. Access the Deluxe Telephone Programming Features as described in Section
3.2.
Program CO Lines for Call Abandon. (700‐723):
2. Enter 02 ‐ CO Line ‐ 09 and press the softkey beneath save . This advances
to the selected CO Line CALL ABANDON programming screen.
3. Toggle the softkey beneath chg for Y/N . Y will allow the selected CO Line
to disconnect where a loop current interruption or polarity reversal is
detected during a call.
4. Press the Volume button (
and repeat steps 2 through 4 for other CO Lines or press the Hold button
h
( ) and follow the prompts to select another CO Line to be
programmed.
5. When finished programming CO Line Call Abandon, press the Volume
v
button ( ) to return to the DB Item Select screen .
v
) to return to the DB Item Select screen
