End-To-End Signaling/Voicemail Dialing Ratio

7.13
Description
This feature allows Deluxe and Standard Model Telephone extensions to generate
in‐band DTMF tones while connected on ICM calls to an on‐site voicemail system
and to ancillary devices connected to the External Page Port.
Default Settings:
Tone Time = 120. (Range is 60‐150.)
Inter Digit Time = 120. (Range is 60‐150.)
Deluxe Telephone Programming
1. Access the Deluxe Telephone Programming Features as described in Section
3.2.
2. Enter 03-34-01 , then press the softkey beneath save . This advances to
the TONE TIME programming screen.
3. Press the softkey beneath chg to select a desired Tone Time. This timer is
relevant only for analog interface voice processing systems connected to
the Emerald ICE analog ports. It is the minimum duration of DTMF tones
delivered to the voicemail analog port for voice processor call processing.
Available selections are 60 , 90 , 120 , and 150 milliseconds
4. Press the softkey beneath next to advance to the INT_DGT TIME
programming screen.
5. Press the softkey beneath chg to select an Inter‐Digit Time. This timer is
relevant only for analog interface voice processing systems connected to
the Emerald ICE analog ports. It is the minimum duration of time between
DTMF tones delivered to the voicemail analog port for voice processor call
processing. Available selections are 60 , 90 , 120 , and 150 milliseconds.
6. Press the Volume button (
Screen or exit programming.
v
) to return to the DB Item Selection
